LokPilot Micro V5.0 DCC decoder, 6-pin plug. ESU 59826
LokPilot Micro V5.0 DCC decoder, with 6-pin plug according to NEM 651. Allows DC and DCC operation. RailCom compatible.
The LokPilot 5 DCC decoder delivers up to 0.75A of motor current (enough power for most motors). It has 4 function outputs which achieve 250 mA load each.
Data sheet
- Marca
- ESU
- Reference
- 59826
- Release year
- 2020
- Size
- 8.0 x 7.0 x 2.9 mm
Description
LokPilot Micro V5.0 DCC decoder, with 6-pin plug according to NEM 651. Allows DC and DCC operation. RailCom compatible.
The LokPilot 5 DCC decoder delivers up to 0.75A of motor current (enough power for most motors). It has 4 function outputs which achieve 250 mA load each.
This decoder stands out for its tiny size: 8.0 x 7.0 x 2.4mm (2.9mm at the capacitor). Thanks to this, it is perfect to install in the smallest locomotives of the N and TT scales.
